DH 40 Thicknesser

Description

Load bearing components are all made of die-cast aluminium, with milled seats for bearings and spindles.

These characterics are essential for vibration-free, smooth thicknessing of soft and hard woods. Triple-spindled table (of die-cast aluminium, flat-milled) which can be accurately adjusted to 1/10mm by handwheel (zero adjustable). Automatic even feed with anti-kickback device: The knurled, spring-mounted infeed roller transports even irregularly shaped work pieces. A rubber-coated outfeed roller prevents marking the newly planed surface. Precision planer block with two HSS planer blades.

Technical Data:
230V. 200W. 50/60Hz. Thicknessing up to 40mm thick and up to 80mm wide. Maximum depth of cut 0.8mm. Cutter speed 6,000rpm. Feed rate 4.8m/min. Table length 232mm. Weight approx. 8kg.

NO 27 040

Spare blades

For thicknesser DH 40. Made of HSS. Length 82mm.

NO 27 042
