DS 230-E Scroll Saw

Description

The ideal machine for the delicate job: model building, toy making and precision mechanics. With electronic speed control.

Cuts soft wood up to 40mm, hard wood up to 10mm, plastics (including PC cards) up to approx. 4mm and non-ferrous metals up to 2mm. Plane-milled die-cast aluminium table (160 x 160mm). Saw frame with 300mm throat made from very stable ribbed die-cast aluminium. Blade guide with integrated blower. Height adjustable head (3 positions) offering two advantages:  Blade usage is improved as the head may be lowered in two steps, making new blade teeth available. This effectively triples blade life.  The lowest head position still allows blades, shortened by 60mm, to be used. Low noise and persevering AC motor with high life expectancy. Quiet and wear-resistant drive via toothed belts. Adjustable mitre fence and angle stop with scale. Includes 5 saw blades (3 coarse-toothed and 2 fine-toothed).

Technical Data:
230V. 85W. Electronically controllable stroke rate from 150 - 2,500rpm. Weight approx 2kg.

NO 27 088

'Super-Cut' scroll saw blades. High quality steel for extended use and prolonged cutting capacity. Standard version without pin.

Hard and soft woods, plastic, Perspex and soft non-ferrous metal.

Coarse-toothed blades         No. 9: 14 teeth per 25mm
NO 28 116                          130 x 1.5 x 0.48mm                 12 pieces

Standard-toothed blades       No. 5: 17 teeth per 25mm
NO 28 117                           130 x 1.20 x 0.38mm               12 pieces

Fine-toothed blades             No. 3: 34 teeth per 25mm
NO 28 118                          130 x 0.8 x 0.34mm 12 pieces

Hard materials such as steel and PERTINAX.

Standard-toothed blades       No. 5: 36 teeth per 25mm
NO 28 112                           130 x 0.85 x 0.4mm                 12 pieces

Fine-toothed blades              No. 3: 41 teeth per 25mm
NO 28 113                           130 x 0.75 x 0.36mm               12 pieces

Very fine-toothed blades        No. 1: 50 teeth per 25mm
NO 28 114                           130 x 0.6 x 0.3mm                   12 pieces
