KT 70 MICRO Compound Table
Product Details:
KT 70 MICRO Compound Table Price And Quantity
- 01 Piece
KT 70 MICRO Compound Table Trade Information
- 10 Piece Per Month
- 15-30 Days
Product Description
MICRO compound table KT 7
Description
Made of solid aluminium with surface treatment and fitted with adjustable dovetail gibs and three T-slots of the MICROMOT standard (12 x 6 x 5mm). Adjustable ruler eases workpiece positioning. Both handwheels have zero-resettable dials with graduations indicating 1 revolution = 1mm and 1 division = 0.05mm. The clamps and securing bolts for the MB 200, MB 140/S and TBM are included.
Other technical data:
Table size 200 x 70mm. X travel 134mm and Y travel 46mm, maximum height 43mm.
NO 27 100
Step clamps made of steel
The step clamps set is supplied with the KT 70, but can also be ordered separately. Set consists of 2 stepped blocks and clamps, T-slot nuts of the MICROMOT standard, bolts. For work pieces up to 20mm thickness.
NO 24 256
