KS 230 Bench Circular Saw

Description

The Super-Cut saw blade ( 58mm) cuts soft wood up to a thickness of 8mm.

Low noise and persevering AC motor with high life expectancy. Power transmission by toothed belt ensures the right blade speed for the job with approx. a doubling of torque. Cutting performance in wood up to 8mm, plastics (also PERTINAX printed circuit boards) up to approx. 3mm, non-ferrous metals up to approx. 1.5mm. Even fibreglass reinforced PC cards can be cut by using a carbide saw blade. Adjustable mitre fence with scale. Angle stop with degree graduation. Flat-milled worktop of die-cast aluminium (160 x 160mm).

Technical Data:

230V. 85 W. 5,000rpm. Weight approx 1.8kg.

NO 27 006

Diamond blade.

50mm diameter (10mm bore). With 0.5mm layer of class D107 diamond for cutting ceramics, porcelain, tiles, stone as well as PC cards.

NO 28 012

Crosscut Super-Cut blade

58mm diameter (10mm bore). 80 alternately set teeth. Ideal for hard and soft wood as well as plastic and Pertinax. For fast, clean cuts. Teeth are individually set and sharpened. Superior cutting power!

NO 28 014

Solid carbide saw blade

50mm diameter (10mm bore). 0.5mm thick. Fine toothed: ideal for cutting fibreglass sheets up to 3mm, non-ferrous metals, duro-plastics and other difficult materials.

NO 28 011

Saw blade made of high-alloy special steel

50mm diameter (10mm bore). Alloy holding a high proportion of tungsten, vanadium and molybdenum for an even structure, high hardness and long lifetime. Fine-toothed. For very fine cuts in non-ferrous metals (aluminium, brass, copper). Also suitable for cutting compound materials like PC cards, and sawing wood and plastics.

N 28 020

Tungsten tipped saw blades

50mm  x 1.1mm (10mm bore). 10 teeth. Used to cut hard and soft woods, PC cards, PERTINAX and aluminium.

NO 28 016

50mm  x 1.1mm (10mm bore). 20 teeth. For extremely clean cuts of balsa, plywood. Can also be used for cutting PC cards and POLYCARBONATE.

NO 28 017
