MICRO shaper MP 400

Description

For chamfering, cutting grooves, slots, recesses, radii and other profiles.

For crafting picture frames and for separating. Also enables exact manufacturing of edges and longitudinal cuts (for model building, e.g. for doors, flaps and housing parts). Powerful dust-protected motor with toothed belt drive. Double ball-bearing spindle. Tool holder with triple slit precision collets (one each of 2.4- 3 and 3.2mm are included).

Milling cutter height adjustment by hand wheel. Stable aluminium table with longitudinal and angle stop as well as cutter guard. Adapter for vacuum cleaner fits standard household vacuum cleaners. Three tungsten carbide router cutters (slot cutter 3.2mm, V-slot cutter and core box bit) are included.

Technical data:
220 -240V. 100W. 50/60Hz. 25.000/min. Height adjustment with scale ring adjustable to 0 (1 revolution = 1, 1 graduation = 0.05mm). Milling table 300 x 150mm. Weight approx. 2.0kg.

NO 27 050

Three tungsten carbide router cutters and three collets are included.

The MP 400 is fitted with a dust collection channel and vacuum adapter. We recommend the use of our compact workshop vacuum cleaner CW-matic.

Tungsten carbide router cutters

For wood, fibreboard and plastics. Clean relief grinding for good work results and surface quality. High stability. Shafts 3.2mm.

NO 29 024
Slot cutter
3.2mm

NO 29 026
Slot cutter 4.3mm

O 29 028
Slot cutter
 6.5mm

NO 29 030
Rounding over
cutter 6.4mm

NO 29 032
V-slot
cutter
6.5mm

NO 29 034
Combi cutter
6.5/2.5mm

NO 29 036
Core box
bit
R 3.2mm

NO 29 038
Rebating cutter
6.4mm

NO 29 040
Edge cutter
with pin
5.0mm

NO 29 044
Angle cutter
45

10-piece wood router cutter set
1 piece each of the cutters offered here. Neatly packed in wooden box.

NO 29 020

Attention:
The wood router cutters offered here may only be used with working devices that have a safety mechanism. For example MICRO shaper MP 400.
