MICRO screwdriver MIS 1

Product Description

Small, light and easy to handle. An ideally positioned rocker switch provides on/off/reverse. A chuck facilitates acceptance of all bit shanks of up to 6.5mm (also for standard 1/4" bits). Housing of glass fibre-reinforced POLYAMIDE. Complete with 16 inserts of chrome molybdenum steel.

• Slot: 0.3 x 1.5 / 0.35 x 2 / 0.4 x 2.5mm
• Philips: Size 0 and 1
• TX: T 6, T 8 and T 10
• Allen key, internal: 3 - 3.5 - 4 - 4.5 - 5mm
• Allen key, external: 1.5 - 2 and 2.5mm

Technical data:

Direct voltage 12 - 18V. 50W. Torques of 0.35 - 1.0Nm (the sixth stage bypasses the clutch and yields approx. 2Nm). Length 200mm. Weight 415g. We recommend the use of MICROMOT mains adapters of at least 2.0A.

Note:

The bit holder shown here (50 x 76 x 15mm - 2 pieces without bits), usable
for holding rotating bits with shaft of  2.35 - 3.0 and 3.2mm is available as
