Long neck Straight drill grinder LBSE
Product Details:
X
Product Description
Head of die-cast aluminium with 75mm long spindle neck (and 20mm MICROMOT collar). Ideal for internal grinding and the use in slots and channels. Special balanced, powerful, quiet and long-lasting DC motor. Variable (full wave) electronic speed control; main housing of glass-fibre reinforced POLYAMIDE. MICROMOT collets (1.0 - 1.5 - 2.0 - 2.4 - 3.0 and 3.2mm). Safely stored in an attractive and extremely stable case made from high-grade polypropylene.
The heart of our MICROMOT precision tools for 230V: the direct current (DC) special motor.
Technical data:
230V. 100W. 5,000 - 22,000/min. Length 300mm. Weight 630g. Insulated to class 2.
MICROMOT steel collets
As described below. For all handheld MICROMOT machines, excluding the Engraver GG 12. One each 1.0 - 1.5 - 2.0 - 2.4 - 3.0 and 3.2mm, clamping nut and holder for storage are included.
Note:
MICROMOT steel collets are hardened and thus have a high, consistent flexibility. They also maintain prolonged accuracy, even after regular use (these collets should not be compared with unhardened, fourslit collets of brass and aluminium). The triple slit collet is substantially more difficult to manufacture than the four-slit type, but offers a better load-bearing surface. This is especially important for cutters with small shaft diameters.
