BBS-S Belt Sander

Description

Powerful special DC motor, quiet and long-lasting.
Left-justified band grinder, making it possible to process surfaces right to the corner. Fine adjustment of rollers prevents lateral rolling off. Easy replacement of bands by means of a spring tension system without the use of tools. Housing is made of glass-fibre reinforced POLYAMIDE. Complete with screw clamp and with 5 x 150 grit and 240 grit grinding bands. Supplied in a practical case as described on page 8.

Technical data:
230V. 150W. Grinding band 40 x 260mm. Grinding surface 60 x 40mm, band speed 160m/min. Length 175mm. Weight 700g. Class 2 insulation.

NO 28 526

Grinding bands made from high-quality corundum (aluminium oxide)
Mounted on a high-performance support. For the grinding of metal, non-ferrous metals, wood and plastics. 40 x 260mm

NO 28 922    80   grit     5 pieces
NO 28 924   150  grit     5 pieces
NO 28 928    240 grit     5 pieces

Sanding pads for OZI/E

High durability corundum (aluminium oxide) pads. Grain filled with special filler to prevent premature clogging. Deposited on special backing paper. Self-adhesive.

NO 28 891    80  grit   25 pieces
NO 28 893   150 grit   25 pieces
NO 28 895   240 grit   25 pieces

HSS cutting blade for OZI/E

Oscillates, making it ideal for cutting metal, wood, PC cards, plastics, plaster of Paris and many other materials. The segment cut facilitates exact cutting right into corners.

NO 28 900      65mm, 160 teeth

Diamond cutting blade for OZI/E

Operation as d e s c r i b e d above for the HSS blade. Cuts marble, bricks, dry walling and many other materials. Ideal for interior finishing and sanitary and electrical installation.

NO 28 902     65mm

HSS immersion saw blades for OZI/E

For exact square excavations and other forms. For making hatchways and windows in ship and aircraft models. Cuts wood, plywood, plastics and aluminium. Max. immersion depth 16mm.

NO 28 897     Saw blade width 8mm
NO 28 898     Saw blade width 14mm
