12-piece SlimLine ring-combination spanner set
Product Details:
X
Product Description
Including holder. To DIN 3113 and ISO 3318.
Carefully hardened and plated. With clearly readable sizes. Ring head offset 15.
Sizes 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 17 and 19mm. Each spanner has a clearly marked place for storage. The plastic holder also offers fixing holes.
Optimal surface protection by means of double nickel-plating and single chrome-plating. With easy to hold, smooth finish.
With durable laser inscribed and clearly readable sizes in mm.
Polished heads: and thin walled. Torque characteristics still exceed DIN/ISO requirements.
Dimensional tolerances are better than those required by DIN/ISO. Each piece is calibrated and checked.
|
NO |
S1 |
B1 |
B2 |
L |
H |
|
23 905 |
5.5mm |
9 |
14 |
93 |
3.0 |
|
23 906 |
6mm |
10 |
16 |
100 |
3.4 |
|
23 907 |
7mm |
12 |
18 |
110 |
3.4 |
|
23 908 |
8mm |
13 |
20 |
120 |
3.5 |
|
23 909 |
9mm |
15 |
22 |
130 |
3.5 |
|
23 910 |
10mm |
16 |
24 |
140 |
4.5 |
|
23 911 |
11mm |
17 |
26 |
150 |
4.5 |
|
23 912 |
12mm |
19 |
28 |
160 |
4.7 |
|
23 913 |
13mm |
20 |
29 |
170 |
4.7 |
|
23 914 |
14mm |
22 |
32 |
180 |
5.5 |
|
23 915 |
15mm |
24 |
34 |
190 |
5.5 |
|
23 916 |
16mm |
25 |
36 |
195 |
6.0 |
|
23 917 |
17mm |
25 |
38 |
210 |
6.0 |
|
23 918 |
18mm |
28 |
38 |
216 |
6.5 |
|
23 919 |
19mm |
28 |
42 |
230 |
6.5 |
|
23 920 |
20mm |
30 |
46 |
250 |
7.5 |
|
23 921 |
21mm |
32 |
45 |
245 |
7.5 |
|
23 922 |
22mm |
33 |
46 |
270 |
7.5 |
|
23 924 |
24mm |
36 |
49 |
280 |
8.5 |
|
23 927 |
27mm |
39 |
55 |
310 |
8.5 |
|
23 930 |
30mm |
44 |
59 |
340 |
9.5 |
|
23 932 |
32mm |
46 |
64 |
360 |
9.5 |
|
23 933 |
34mm |
50 |
70 |
380 |
15 |
|
23 935 |
36mm |
54 |
74 |
410 |
18 |
|
23 937 |
41mm |
61 |
84 |
460 |
21 |
